DC Systems Analysis Modules
The DC System Analysis modules include Battery Sizing, DC Load Flow, DC Short Circuit (ANSI), and DC Short Circuit (IEC).

A downloadable version of the DC Systems brochure is available in PDF format via a link at the bottom of this page.
Compliance with Industry Standards
  • Battery Sizing - IEEE standard 485 for sizing Lead-Acid batteries and IEEE standard 1115-2000 for sizing Nickel-Cadmium batteries, determines the size of batteries to supply the worse case DC duty cycle loads and AC emergency loads.
  • DC Load Flow - Calculates power, current and voltage drop profiles. Represents constant kW, I, and Z, load types and evaluates all loading conditions for duty cycle loads and AC emergency loads.
  • DC Short Circuit - ANSI standard 399 and 946, calculates the initial rate of rise and peak fault current.
  • DC Short Circuit - IEC standard 61660, calculates the peak fault current, time constants, time to peak, and steady state conditions.
Benefits
  • Save time with intuitive scenario manager interface.
  • Communicate designs effectively with graphical and text base results.
  • Improve decisions by quickly comparing resulting curves from different scenarios.
  • Increase productivity by modelling both DC and AC systems in a single project.
  • Reduce mistakes by evaluating all loading conditions and duty cycle loads.
  • Battery Sizing and Load Flow automatically calculates AC emergency loads and their impact on the DC system to help you design safer and more reliable systems.
DC Equipment Library
  • Battery Library - Rt Curve and Discharge Curve for Lead-Acid and Nickel-Cadmium batteries.
  • DC Generator Library - Name Plate data, Transient Resistance and Inductance.
  • DC Motor Library - Name Plate data, Transient Resistance and Inductance.
DC Component Types
Create models of different types of direct-current components including those listed below.
  • Lead-Acid Battery
  • Nickel-Cadmium Battery
  • Rectifier
  • DC Cable
  • DC Bus/Node
  • DC Load
  • DC Motor
  • Train
  • DC Generator
  • Inverter/UPS
  • DC-DC Converter
  • DC Capacitor
A downloadable version of the DC Systems brochure is available here.
PDF 0.1Mb
